Flight Mode Control
Support The Fixed Wing Vertical Takeoff And Landing : Greatly Reduce Dependence On The Site, Ejection Rack, Parachute, Etc., And The Operating Site Is Wide Adapted.Dual-Redundancy GNSS Positioning.
Video Camera Control
Support Real-Time Monitor Height And Distance,GPS Star Number, Flight Status Real-Time Dispay.Real-Time Display Flying Height, Distance, Heading Angle.Support The Fist View Monitoring.
One Key Return
Out Of Control Return, Flight Direction Lock, Law Battery Alarm And Data Recorder.Manual Stability, Autonomous Take-Off/Landing,Flying Attitude Stability/GPS Attitude Stability.
Waypoint Route Planning
Built-In Black Box Data Recording Function, Can Be Recorded About 60 Minutes Of Flight Data. Support For Connecting External Data Loggers, Record Up To 2000 Hours Of Flight Data.
EN
Drone Gimbal Camera with Daylight and Thermal Imaging YPO-05P
Drone Gimbal Camera with Daylight and Thermal Imaging YPO-05P
description1
Zipper closure
1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in
place during workout
Product Description
Digital Eagle cameras are suitable for the environment that requires a higher level surveillance protection, with water-proof dust-proof and salt fog-proof features. The cameras are integrated with high-definition visible light, infrared thermal imaging, auto tracking and laser range finder modules. The cameras can achieve day and night vision surveillance, temperature measurement, target tracking, laser range finding and other additional features, greatly facilitating the system used in various industries.
Digital Eagle cameras can be mounted on multi rotor drones, fixed wing drones, VTOL drone, helicopter, aircraft and other types of flying vehicles.
Technical Data Sheet
|
Model |
YPO-05P |
|
Material Science |
ABS |
|
Size |
135mm*200*220mm |
|
Transaction mode |
50% T/T in advance, 50% T/T before loading |
|
Delivery time |
2 weeks |
|
Packing |
Aviation aluminum box |
|
Color |
Black |
|
Place of origin |
Wuxi, China |
|
Minimum order quantity |
1 unit |
Two-Axis 360° Stable System 30X Optical Zoom HD Camera
Image enhancement:TIE Digital Image Detail Enhancement Technique with Edge
Sharpening
Image noise reduction:Digital filtering
Field of view angle 19.5°x14.7°（32.0°x24.2°）
Technical Data Sheet
Visible light parameter-EO
|
Video record |
1920*1080 |
AIS advanced image stable |
|
|
Optical zoom |
30x |
Storage Options |
SD/SDHC memory card |
|
Pixels |
2 million |
Focal length |
F=4.3~129mm |
Thermal imaging parameter-IR
|
Wavelength range |
8-14um |
Pixel |
2 Million |
|
Power consumption |
2.5w |
Frame frequency |
50Hz |
|
Image output |
＜5s |
Digital zoom |
Physical Electrical Performance Parameter
|
Diameter |
135mm |
Rotational angular velocity |
≤120°/s |
|
Demension |
135mm*200*220mm |
Steady angular velocity |
≥1°/s |
|
Weight |
1.7kg |
Pitch |
+30°~-90° |
|
Stabilization accuracy |
better than 0.1° |
Roll: ±30° |
Yaw: ±170°N |
|
Video output |
HDMI |
Operating temperature |
-20℃~50℃ |
Wide Application
-
Daytime image with 30x optical zoom
-
One key switch to thermal lens
-
Thermal image for night vision,picture in picture
-
Target tracking for security monitor
Product Features
YPO-05P Drone Accessories HD EO/IR 2 Axis Drone Camera
Both daytime and night imaging
Point zoom tracking
Real time video transmission to command center
Mounted on multi-rotor drones/fixed-wing drone
