Digital Eagle YT-08 Dual Lights PTZ Camera

description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Product Description

Digital Eagle cameras are suitable for the environment that requires a higher level surveillance protection, with water-proof dust-proof and salt fog-proof features. The cameras are integrated with high-definition visible light, infrared thermal imaging, auto tracking finder modules. The cameras can achieve day and night vision surveillance,  temperature measurement, target tracking finding and other additional features, greatly facilitating the system used in various industries. Digital Eagle cameras can be mounted on multi rotor drones, fixed wing drones, VTOL drone, helicopter, aircraft and other types of flying vehicles.

Technical Data Sheet

Model

YT-08 Dual Lights EO/IR Camera

Material Science

ABS

Size

113mm*123*155mm

Transaction mode

50% T/T in advance, 50% T/T before loading

Delivery time

2 weeks

Packing

Aviation aluminum box

Color

Black/White

Place of origin

Wuxi, China

Minimum order quantity

1 unit

Starlight camera 10x optical zoom PTZ camera clearly imaging in low light

TIE Digital Image Detail Enhancement Technique with Edge Sharpening

Image noise reduction:Digital filtering
Field of view angle 19.5°x14.7°(32.0°x24.2°)



Technical Data Sheet
Visible light parameter

Optical zoom factor

10x zoom

Video format

1080p

Pixels

2 million pixels

Lens focal length

F=4.9mm(wide-angle)to 49mm(remote)

Temperature range

-20 degree ~ 60 degree

Power consumption

2W (zoom work/no focus ) 3.7 W (zoom and focus both work)

Physical Electrical Performance Parameter

Stability system

Directional pitch two axis structure

Various rotation angles

Pitch +30°~-90, Yaw 360°

Stable accuracy

Better than 0.1 degree

Power supply

12v DC input, total power consumption is less than 15w

Speed range

The maximum rotational angular speed is 30 degree /s

Diameter

113mm

Minimum steady angular velocity

less than 1 degree/s

Stability system

Two axis structure

Weight

<890g

Size

113mm*123mm*155mm

Thermal imaging parameter

Pixels

640*480

Wavelength range

8~14μm

Power consumption

2.5W

NETD

≤50mk@25℃

Image noise reduction

Digital filtering

Frame rate

50Hz

Video output

HDMI

Mage enhancement

TIE Digital Image Detail Enhancement Technique with Edge Sharpening

Operating temperature

-20℃~+60℃

Humidity

≤95%( Non-condensing)

Electronic zoom

2x 4x 8x 16x

Field of view angle

19.5*14.7

Laser Rrange Finder Parameter

Range

2000m

Beam Divergence

3mrad

Resolution

0.5m

Frame rate

50Hz

Beam

905nm pulse laser

Video output

HDMI

Wide Application
  • Daytime image with 30x optical zoom
  • One key switch to thermal lens
  • Thermal image for night vision,picture in picture
  • Target tracking for security monitor
FAQ
  • Which certificate do you have for your equipment?

    We have ISO9001, ISO14001, CE certificate

    1
  • What can I buy from you?

    Agriculture Drone, Multi-rotor Drone, Fixed Wing Drone, Drone Camera, Anti Drone Device.

    2
  • If OEM is acceptable?

    Yes. We can do OEM.

    3
  • What is your term of payment?

    50% T/T in advance, 50% T/T before delivery

    4
  • What's your advantage compared with other suppliers?

    Own R&D center, five factories in China- More than 400 patents. - Professional teams - Long time practical experiences - Global markets coverage.

    5
  • How do you provide training service?

    All our products are modular-design, which is easy to operate and maintain for anyone from anywhere. We also provide on-line courses and 3-5 day on-site training in our company. Every client will be required to pass the exam before operating.

    6
