Digital Eagle YPO-25 Drone UAV Camera with Thermal Imaging and Laser Range Finder

Digital Eagle YPO-25 Drone UAV Camera with Thermal Imaging and Laser Range Finder

description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Product Description

Stability system:Directional pitch two axis structure

Stable accuracy:Better than 0.1 degree

Speed range:The maximum rotational angular speed is 30 degree /s, the

minimum steady angular velocity is less than 1 degree/s

Technical Data Sheet

Model

YPO-25 EO/IR/LRF Camera

Material Science

ABS

Size

135mm*200*220mm

Transaction mode

50% T/T in advance, 50% T/T before loading

Delivery time

2 weeks

Packing

Aviation aluminum box

Color

Black

Place of origin

Wuxi, China

Minimum order quantity

1 unit

Three-Axis 360° Stable System 40X Optical Zoom HD Camera

TIE Digital Image Detail Enhancement Technique with Edge Sharpening

Image noise reduction:Digital filtering
Field of view angle 19.5°x14.7°(32.0°x24.2°)

Technical Data Sheet
Visible light parameter

Stability system

Directional pitch two axis structure

Various rotation angles

Pitch +30°~-90, Yaw 360°

Stable accuracy

Better than 0.1 degree

Power supply

12v DC input, total power consumption is less than 15w

Speed range

The maximum rotational angular speed is 30 degree /s

Diameter

180mm

Minimum steady angular velocity

less than 1 degree/s

Stability system

Two axis structure

Weight

<2kg

Size

180mm*180mm*240mm

Physical Electrical Performance Parameter

Stability system

Directional pitch two axis structure

Various rotation angles

Pitch +30°~-90, Yaw 360°

Stable accuracy

Better than 0.1 degree

Power supply

12v DC input, total power consumption is less than 15w

Speed range

The maximum rotational angular speed is 30 degree /s

Diameter

180mm

Minimum steady angular velocity is less than 1 degree/s

Stability system

Two axis structure

Weight

<2kg

Size

180mm*180mm*240mm

Thermal imaging parameter

Pixels

640*480

Wavelength range

8~14μm

Power consumption

2.5W

NETD

≤50mk@25℃

Image noise reduction

Digital filtering

Frame rate

50Hz

Video output

HDMI

Mage enhancement

TIE Digital Image Detail Enhancement Technique with Edge Sharpening

Operating temperature

-20℃~+60℃

Humidity

≤95%( Non-condensing)

Electronic zoom

2x 4x  Electronic zoom

Field of view angle

19.5*14.7

Laser Rrange Finder Parameter

Range

2000m

Beam Divergence

3mrad

Resolution

0.5m

Frame rate

50Hz

Beam

905nm pulse laser

Video output

HDMI

Wide Application
  • Daytime image with 30x optical zoom
  • One key switch to thermal lens
  • Thermal image for night vision,picture in picture
  • Target tracking for security monitor
Product Features

YPO-25 Drone Accessories HD EO/IR/RF 3 Axis Drone Camera

Both daytime and night imaging

Point zoom tracking

Real time video transmission to command center

Mounted on multi-rotor drones/fixed-wing drone
